Abstract

We present high-resolution magnetic field maps of the M17 SW molecular cloud using JCMT 850 m dust polarization at a scale of 14. The magnetic field exhibits a distinct arc-like structure that encircles three dense clumps (C1, C2, and C3). By combining polarization data with ammonia line observations, the plane-of-sky magnetic field strength, measured using the Skalidis-Tassis method to minimize angle dispersion errors, ranges from 0.1 to 2.4 mG (mean: 0.54 mG). Energy budget analysis reveals a hierarchy dominated by gravity ( erg cm), which exceeds both magnetic ( erg cm) and turbulent ( erg cm) energies. Since all three energy densities lie within one order of magnitude, gravitational dominance acts primarily as the global driver, while the system remains in a state of near-equipartition. Structurally, the northeastern boundary shows magnetic field lines perpendicular to the shock front, consistent with compression from the adjacent HII region. Within the cloud, magnetic field lines generally align with gravity to assist collapse, but turn perpendicular to gravity within curved accretion bridges. This configuration provides support against radial collapse while guiding gas flow. Kinematic evidence suggests that these channels transport material from Clump C3 onto the massive Clump C2. Star formation in M17 SW is globally driven by gravity but locally regulated by the magnetic field structure.
